What Is the Santa Cruz Tallboy and Who Is It For?
The Tallboy is Santa Cruz's short-travel trail bike with 140/130mm of front/rear suspension travel and 29" wheels.
It's made for the rider who wants to do quick rips up to the trailhead after work, big back-country pedals and long hours in the saddle. Tallboy is light and efficient enough to climb well, but still plenty capable down the hill. It's a perfect balance of speed and capability.
No More VPP?
While Santa Cruz is famous for their VPP suspension design, this 6th generation Santa Cruz Tallboy was changed to a four-bar design to save weight, improve suspension kinematics and increase the seat post insertion depth to allow longer droppers. VPP is a great system that works super well on their longer travel bikes. But, the more simple and lighter four-bar layout makes a lot of sense on a shorter travel bike that would benefit less from VPP.
The new four-bar layout on the Tallboy has lower anti-squat and anti-rise, which still provide a lot of traction, while keeping the bike light and playful like a 140/130mm bike should be.
The Geometry - Let's Crunch Some Numbers
| XS | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|
| Reach (Hi/Lo) | 410/407 | 435/432 | 455/452 | 475/472 | 495/492 | 520/517 |
| Stack (Hi/Lo) | 601/603 | 610/612 | 624/626 | 633/635 | 646/649 | 660/662 |
| Head Tube Angle (Hi/Lo) | 65.1°/64.8° | 65.1°/64.8° | 65.1°/64.8° | 65.1°/64.8° | 65.1°/64.8° | 65.1°/64.8° |
| Head Tube Length | 90 | 100 | 115 | 125 | 140 | 155 |
| Rear Center (Hi/Lo) | 435/435.5 | 435/435.5 | 435/435.5 | 438/438.5 | 440/440.5 | 444/444.5 |
| Front Center (Hi/Lo) | 721/721 | 750/750 | 777/776 | 801/801 | 827/827 | 858/858 |
| BB Height (Hi/Lo) | 336/333 | 336/333 | 336/333 | 336/333 | 336/333 | 336/333 |
| BB Drop (Hi/Lo) | 36/39 | 36/39 | 36/39 | 36/39 | 36/39 | 36/39 |
| Wheelbase (Hi/Lo) | 1156/1156 | 1185/1186 | 1212/1212 | 1239/1239 | 1267/1267 | 1302/1303 |
| Top Tube Length (Hi/Lo) | 542/542 | 569/570 | 596/596 | 616/616 | 637/638 | 666/666 |
| Seat Tube Length (Hi/Lo) | 360/370 | 380/380 | 400/400 | 420/430 | 450/450 | 500/500 |
| Seat Tube Angle (Hi/Lo) | 77.6°/77.3° | 77.6°/77.3° | 77.3°/77° | 77.4°/77.2° | 77.5°/77.3° | 77.5°/77.3° |
| Seat Tube Angle at Saddle Height (Hi/Lo) | 77.4/77.1 at 640 | 77/76.8 at 680 | 76.5/76.3 at 730 | 76.5/76.3 at 780 | 76.5/76.3 at 830 | 76.5/76.3 at 870 |
| Standover Height (Hi/Lo) | 699/695 | 703/699 | 718/714 | 728/725 | 742/739 | 758/755 |
Sizing
Sizing can always vary due to preference and body proportions, of course. When it comes to preference, if you want a more stable bike, the larger frame will do that while the shorter frame will be more nimble with its shorter wheelbase.
Here's a general size guide based on height.
X-Small: 410mm reach for riders 142-154cm tall
Small: 435mm reach for riders 154-165cm tall
Medium: 455mm reach for riders 165-175cm tall
Large: 475mm reach for riders 175-185cm tall
X-Large: 495mm reach for riders 185-193cm tall
XX-Large: 520mm reach for riders 193-200cm tall
How Does the Tallboy Compare to the Blur or Bronson?
| Blur | Tallboy | Bronson | |
|---|---|---|---|
| Wheel Size | 29" | 29" | 29/27.5" |
| Travel Front/Rear | 120mm | 140/130mm | 160/150mm |
| Weight | 12.06kg (GX AXS Race Reserve | 13.47kg (XT Di2) | 15.06kg (GX AXS) |
| Intended Purpose | Focused on pedalling efficiency for XC racing, adventure racing/riding and even bikepacking. | Short-travel trail bike for big days in the saddle on epic trails where you really need efficiency but still want capability. | All-around core trail e-bike that's good for both flowy blue trails and the more technical trails with an emphasis on handling. |
What specs and colours of Santa Cruz Tallboy are available?
Tallboy CC Deore - CC Carbon frame, Rockshox Pike & Deluxe Select+, Shimano Deore 12speed, SRAM DB8 brakes.
Tallboy CC 90 - CC Carbon frame, Rockshox Pike & Deluxe Select+, SRAM 90 T-Type, DB8 brakes
Tallboy CC GX AXS - CC Carbon frame, Rockshox Pike Select+, Deluxe Select+, SRAM GX AXS, SRAM Motive Bronze brakes
Tallboy CC XT Di2 - CC Carbon frame, Rockshox Pike Ultimate, Deluxe Ultimate, Shimano XT Di2, SRAM Motive Silver.
Tallboy CC X0 AXS Reserve - CC Carbon frame, Rockshox Pike Ultimate, Deluxe Ultimate, SRAM X0 T-Type, Motive Silver brakes
What is the warranty on a Santa Cruz Tallboy?
Santa Cruz frames come with a lifetime warranty for the original owner. They also offer free replacement pivot bearings to the original owner for as long as they own the bike. Their Reserve Carbon wheels have a lifetime warranty on the rim for damage done while riding. Bosch components have a two-year manufacturer's warranty.
